Government Rebate Eligible (CEC Certified) – BSL 48V 100Ah 5.12kWh Rack Mount Lithium LiFePO4 Battery

BSL Batteries 48V 100Ah Rack Mount LiFePO4 Battery – Model B-LFP48-100E 3U

Eligible for government rebates and grants: This battery qualifies for government solar rebates and grants when installed by a licensed battery installer.

• Certified for Grid-Connected Systems
• Fully CEC-certified for integration into grid-connected solar setups
• Victron-certified and BMS-compatible with leading inverter brands including Growatt, Goodwe, and more
• Seamless integration with smart inverter systems for real-time monitoring and management
• Premium Energy Storage for Demanding Applications

The BSL B-LFP48-100E 3U is a high-performance 48V 100Ah LiFePO4 battery engineered for demanding residential, commercial, and industrial environments. Compact and rugged, its 3U rack-mount design ensures easy scalability while delivering safe, stable, and efficient energy storage.

Key Technical Specifications:

• Nominal Voltage: 51.2V
• Nominal Capacity: 5120Wh
• Usable Capacity: 4608Wh
• Cell Configuration: 16S1P (16 series, 1 parallel)
• Dimensions (W x H x D): 540 (incl handles) x 483 x 180 mm
• Weight: 46kg
• Performance & Efficiency:
• Discharge Voltage Range: 46V – 55V
• Charge Voltage Range: 54V – 58V
• Depth of Discharge (DoD): 90%
• Rated Discharge Current: 80A (4.096kW)
• Rated Charge Current: 50A (2.56kW)
• Max Discharge Current: 110A (5.632kW)
• Max Charge Current: 120A (6.144kW for 1s)
• Peak Discharge Current: 150A (7.68kW for 1s)
• Built for Reliability & Safety:
• Operating Temperature: 0°C to 55°C
• Storage Temperature: -20°C to 55°C
• Humidity Range: ≤60% RH
• Altitude Rating: Suitable up to 4000m
• Protection Features:
• Advanced BMS with protections against overcharge, over-discharge, overcurrent
• Short-circuit protection with 500μs response time
• Cooling: Passive thermal management
• Ingress Rating: IP20 (protection against solid objects >12mm)
• Certifications: UN38.3 certified for global transport and safety compliance
• Long Lifespan & Minimal Maintenance:
• Cycle Life: >6000 cycles at 25°C
• Warranty: 10 years
• Design Life: Over 15 years under typical conditions
• Self-Discharge Rate: ≤3% per month
• Eco-Friendly & Scalable:
• Sustainable Chemistry: Non-toxic, highly recyclable LiFePO4 composition
• Modular Expansion:
• Base capacity: 5.12 kWh
• Expandable up to 63 units in parallel
• Total Scalable Capacity: Up to 322.56 kWh
• Ideal for:
• Home solar storage
• Commercial energy management
• Industrial off-grid or hybrid systems

Whether you're building a solar-powered home system or managing large-scale energy infrastructure, the BSL B-LFP48-100E offers the reliability, safety, and flexibility to meet your storage needs.
